Trace 30
OverviewAbout the Apollo Trace 30
The Apollo Trace 30 is a commuter bike, built on a aluminium frame, listed at $1,049. An upright, practical bike for getting around town.
SizingWhat size Trace 30 do I need?
Enter your height to see the size Apollo recommends.
| Size | Rider height | In feet |
|---|---|---|
| S | 158 to 168 cm | 5 ft 2 in to 5 ft 6 in |
| M | 165 to 173 cm | 5 ft 5 in to 5 ft 8 in |
| L | 170 to 178 cm | 5 ft 7 in to 5 ft 10 in |
| XL | 175 to 190 cm | 5 ft 9 in to 6 ft 3 in |
Rider heights from Apollo's size chart. Height is a starting point: arm and leg length, flexibility and riding style all matter, so a test ride beats any chart. How bike sizing works.
SpecificationsWhat we know
- Brand
- Apollo
- Model year
- 2026
- Category
- Commuter
- Frame
- Aluminium
- Wheel size
- 700c
- Drivetrain
- Shimano Altus 3x9-speed
- Brakes
- Disc
- Frame sizes
- S, M, L, XL
- Price
- $1,049, RRP AUD (Ivanhoe Cycles)
Specs and pricing are listed in AUD and sourced from Australian retail listings. Confirm the current details and availability with the seller before purchase.
GeometrySize M
- Stack
- 592 mm
- Reach
- 400 mm
- Stack/reach
- 1.48
- Head angle
- 71.5 deg
- Seat angle
- 73.5 deg
- Wheelbase
- 1066 mm
- Chainstay
- 440 mm
- BB drop
- 50 mm
GearingRatios
Ratios are derived from the chainrings and cassette. They describe the gearing, not any rider's ability.
Drivetrain & buildFull specification
- Speeds
- 9
- Crank
- Shimano FC-T3010, 170mm (S/M) or 175mm (L/XL)
- Chainrings
- 48/36/26
- Cassette
- 11-32
- Brakes
- Tektro HD-T275 hydraulic disc brakes
- Rotors
- 160mm
- Wheelset
- 700c Weinmann U-26 double wall disc specific rims, alloy quick release disc hubs, stainless spokes
- Stock tyre
- 700x40c
- Fork material
- Alloy
Bike DNAWhat the numbers say
- Position
- Stack-to-reach 1.48 gives a balanced, endurance riding position.
- Steering
- A 71.5 deg head angle points to balanced steering.
- Climbing
- Lowest ratio 0.81 is a very low climbing gear for steep or loaded climbs.
Derived from the published geometry and gearing above. It describes the numbers, not a ride test.
BikeFinder Data Profile: geometry and specification researched from published sources (backfill 2026-09-27: apollobikes.com), verified 2026-09-27. This is a specification analysis, not a physical ride review.
Where to buyStockist
BikeFinder is an independent directory. We link to retailers; the price shown is last seen and set by the seller.
